This machine is not in stock.
Technical specifications
| Condition | New |
|---|---|
| Max swing over bed (mm) | 510 |
| Centre distance (mm) | 3000 - 1000 |
| Spindle bore (mm) | 80 |
| Year of Manufacture | NEW |
| Control | FAGOR/FANUC/SIEMENS |
| Max swing over cross slide (mm) | 340 |
| Max swing in gap (mm) | 760 |
| R.P.M. | 26 - 2400 3 steps |
| kW | 11/15.5-11/15-9 |
| Volts (V) | 400 |
| Cycles (Hz) | 50 |
Included parts & extra info
Main spindle motor
Automatic speed changer
Fully enclosure
Gap bed
Tailstock
Coolant system
Lubrication system
Low voltage circuit system
CE
Leveling pads
Tool set & kits
Operation manual & parts list
Portable MPG
Lighting
Full specifications of different controls available on request.
Options also on request.
