This machine is not in stock.
Technical specifications
| Condition | New |
|---|---|
| Max swing over bed (mm) | 560 |
| Centre distance (mm) | 934-1442-1950-2966 |
| Spindle bore (mm) | 80 |
| Year of Manufacture | NEW |
| Control | FANUC 0iTF PLUS or SIEMENS 828 |
| Max swing over cross slide (mm) | 390 |
| Max swing in gap (mm) | 810 |
| R.P.M. | 26-266 / 267-766/ 767-2400 |
Included parts & extra info
- FANUC 0iTF PLUS control and ß12i spindle servomotor with Manual Guide i, 10.4” color LCD
- or
- SIEMENS 828 control system & 1PH8131 spindle servo motor, with Shopturn software
- Automatic lubrication in headstock and slide ways & ball screws
- Automatic spindle speed gear change (2400rpm)
- Cutting fluid coolant system
- Full length rear splash guard
- Front moveable chip trolley
- Full enclosed end guard
- Round type guarding
- Working light
- Leveling block
- Centers and center sleeve
- Service tools & toolbox
- Operation, programming & instruction manual
